CM LODESTAR Electric Chain Hoist
Capacity 250 – 3000kg.
The Lodestar hoist is a tough and durable electric chain hoist, designed to keep working in the most arduous applications.
This hoist is recognised and proven within the hire industry as the number one hoist, where high duty, combined with long heights of lift are required. From hook suspension in the rental industry to trolley mounted in a factory production line, the LODESTAR has a proven reputation as the solution for industrial strength lifting.
Standard Operating Voltage: 110v 1ph 50Hz, 230 1ph 50Hz and 400v 3ph 50Hz
Spare parts are available, please contact a member of Durham Lifting’s Sales Team.
Available from Durham Lifting. Fast dispatch from the UK.
Description
Technical Data
Description
- Tough lightweight aluminium alloy covers totally enclose the mechanical and electrical components providing protection and efficient heat dissipation. The design enables easy access for installation and service.
- Adjustable upper and lower limit switches.
- 48v control, IP65 pendant as standard.
- Thermal overload protection as standard.
- FEM classification 2m (50 duty – 30 minutes continuous use per hour)
- Motor classification H4.
- Excellent closed height dimensions.
- A lifetime lubricated gearbox contributes to exceptional service and maintenance characteristics.
- Single phase hoist supplied with handles and 1mtr supply with Cee-Form plug.
- 3-phase single speed hoist motors are dual voltage.
- Load hook with axial bearing.
- Ideal for long heights of lift.
Technical Data
| Model | Operating Voltage | Capacity (WLL) kg | Falls of Load Chain | Lifting Speed(s) m/min | Load Chain Depth x Pitch mm | Hoist Motor kW |
| C | 230v OR 110v 1ph 50Hz | 250 | 1 | 8 | 6.3 x 18.9 | 0.37 |
| F | 230v OR 110v 1ph 50Hz | 500 | 1 | 4 | 6.3 x 18.9 | 0.37 |
| J | 230v OR 110v 1ph 50Hz | 500 | 1 | 8 | 7.9 x 21.7 | 0.75 |
| L | 230v OR 110v 1ph 50Hz | 1000 | 1 | 4 | 7.9 x 21.7 | 0.75 |
| LL | 400v 3ph 50Hz | 1000 | 1 | 8 | 7.9 x 21.7 | 0.75 |
| LL2 | 400v 3ph 50Hz | 1000 | 1 | 8/2.5 | 7.9 x 21.7 | 0.75 |
| R | 230v OR 110v 1ph 50Hz | 2000 | 2 | 2 | 7.9 x 21.7 | 0.75 |
| RR | 400v 3ph 50Hz | 2000 | 2 | 4 | 7.9 x 21.7 | 0.75 |
| RR2 | 400v 3ph 50Hz | 2000 | 2 | 4/1.3 | 7.9 x 21.7 | 0.75 |
| RT | 230v OR 110v 1ph 50Hz | 3000 | 3 | 1.33 | 7.9 x 21.7 | 0.75 |
